Smarteye IP Camera 636JBU

 Hardware Features

                  Interface

WI-FI   Support

Power   Interface

Reset   Button

36 infrared LED, 25m distance

                    Pan/Tilt

N/A

               Image Sensor

1/4” CMOS Sensor

            Display Resolution

1280*720/640*360

                       Lens

Mega Pixel lens,f=3.6mm，F=2.2,View angle:60 degree

                   Dimension

196*65*65mm

                 Power Input

12V 1A DC,<8W

 Wireless

 Features

              Wireless Speed

IEEE802.11b/g/n   150Mbps

           Operating Frequency

2.4GHz

                    Channel

1~13

                    Security

WPA/WPA2,WPA-PSK/WPA2-PSK

                      WPS

One key configure wifi

  Software    Features

            Protocols & Standards

TCP/IP,   DHCP,  FTP,   SMTP，NTP,   UPNP,HTTP, UDP/IP，DDNS     P2P

             Image Compression

H.264

                  Image Settings

Image   Settings:Saturation,   brightness, contrast adjustable through client software   or web browser

              Maximal Frame Rate

25fps

                     Code rate

256kbps~2048kbps

              Account permissions

Three   Level

                Motion Detection

Support   Four motion detection,send alarm pictures or video to Micro SD.send alarm   pictures to FTP/Email.

              Manage Software

P2P   View client software   (support Android, iPhone),
          IP / DDNS View client software (support Android，iPhone),
          PC centralized control and management platform

                        Audio

Two-way     audio，Audio Compression: G.711

                 PC Requirements

CPU     2.0GHz or above (suggested 3.0GHz)

Memory     Size 256MB or above (suggested 1.0GHz)

Display     Card 64M or above

Windows     8,7,10，XP,Mac   OS

Browser:IE7/IE8/IE9/IE10/IE11,Firefox,Safari,Goolge     Chrome,other standard browsers

           SmartPhone requirements

Android version 4.5 and above; iOS version 7.0 and above; Windows Phone uses browser to view or the third party APPs.

                        Other parameters

           Package Contents

One   IP-Camera

One   Power adapter
Mounting bracket set

One   Quick Guide

               Temperature

Operate     Temper：-10℃ ~ ,40℃，Storage Temper：-20℃     ~ 70℃

                   Humidity

Operating     Humidity：10%   ~ 90%，Storage   Humidity：5%     ~ 98%

                    certificates

CE,FCC
