| Specifications | |
| Main IC | T23N |
| Image Sensor | 1/3-inch cmos sensor |
| Display Resolution | 1296P (2304*1296P) /3MP |
| Mini. Illumination | 2 Lux (with infrared led on) |
| Focal Length | 3.6mm |
| Viewing Angle(D/H/V) | 95°/80°/45° |
| LED | 4 960nm LED infrared distance up to 7 meters |
| Day night mode | IR cut filter with auto switch |
| Image Compression | H.265 |
| Mirrow flip | Support |
| View mode | HD & SD |
| Audio | Built-in Mic & Speaker |
| Supported protocols | TCP/IP, RTSP, DHCP,NTP,ONVIF,UDP/IP,HTTP |
| Dynamic DNS | Support |
| Stream | Dual Stream |
| wireless | IEEE802.11b/g/n 150Mbps |
| Frequency | 2.4G |
| Antennas | built-in |
| Antenna gain | 3dB |
| Wireless Security | 64/128-bit WEP, WPA/WPA2,WPA-PSK/WPA2-PSK |
| Range | Horizontal: 320 degree |
| Vertical: 70 degree | |
| Remote management | Yes APP remote |
| Multiple user management | Support (in app) |
| Split screen view | Support (in app) |
| Mobile app | IOS & Android |
| Motion detection | Support |
| Notification method | Mobile Push |
| Remote Access | P2P |
| LED indicator Light | red,blue |
| Storage | Micro SD Card up to 128GB |
| Cloud | Support cloud storage |
| Certifications | CE,FCC |
| Alexa | Support |
| Google Home | Support |
| Bare metal weight(g) | 166g |
| Bare metal size | 73.5*73.5*101.8mm |
| Bare package weight (g) | |
| Bare metal package size | 115*85*115mm |
| Packing Quantity | 1=45 |
| Maximum power consumption | <3.75w |
| Power parameters | 5V1A TypeC |
| Working Temperature | -10°C ~ 50°C |
| Working Humidity | 20% ~ 95% non-condensing |
