| Specifications | |
| Main IC | T31ZL |
| Image Sensor | 1/2.9-inch cmos sensor |
| Display Resolution | 1296P (2304*1296P) /3MP |
| Mini. Illumination | 2Lux (with infrared led on) |
| Focal Length | 4mm |
| Viewing Angle(D/H/V) | 100°/85°/47° |
| LED | 6pcs 850nm LED IR distance up to 7 meters |
| Day night mode | IR cut filter with auto switch |
| Image Compression | H.265 |
| Mirrow flip | Support |
| View mode | HD & SD |
| Audio | Built-in Mic & Speaker |
| Supported protocols | TCP/IP, DHCP,NTP,UDP/IP,HTTP |
| Dynamic DNS | Support |
| Stream | Dual Stream |
| wireless | IEEE802.11b/g/n 150Mbps |
| Frequency | 2.4G |
| Antennas | Built-in |
| Antenna gain | 3dB |
| Wireless Security | 64/128-bit WEP, WPA/WPA2,WPA-PSK/WPA2-PSK |
| Range | Horizontal: N/A |
| Vertical: N/A | |
| Waterproof and dustproof grade | IP66 |
| Remote management | Yes APP remote |
| Multiple user management | Support (in app) |
| Split screen view | Support (in app) |
| Mobile app | IOS & Android |
| Motion detection | Support, PIR sensitivity can be adjusted in three gears, the maximum is 7 meters |
| Notification method | Mobile Push |
| Remote Access | P2P |
| LED indicator Light | Blue, Red |
| Storage | Local storage MicroSD card up to 128G |
| Cloud | Support cloud storage |
| Certifications | CE,FCC |
| Alexa | Support |
| Google Home | N/A |
| Bare metal weight(g) | 235g(with bracket) |
| Bare metal size | 54.4*62*88.3mm |
| Bare package weight (g) | |
| Bare metal package size | |
| Packing Quantity | |
| Maximum power consumption | 6.5W |
| Power | DC5V 1A Type-C(without adapter) |
| Built-in 2 parallel-connected 18650 lithium battery packs 5000ma | |
| Working Temperature | -10°C ~ 50°C |
| Working Humidity | 20% ~ 95% non-condensing |
